Touch the Light Fantastic

Short laser bursts create a finger-friendly 3-D hologram in midair.

By Jonathon Keats
Nov 30, 2015 6:00 AMApr 18, 2020 10:48 PM
Touch Laser - University of Tsukuba
(Credit: Yoichi Ochiai/University of Tsukuba)


Sign up for our email newsletter for the latest science news

At a Los Angeles tech show in August, Japanese researchers vaporized visitors’ fingertips with high-energy lasers. They were not demonstrating a new form of torture. On the contrary, says principal investigator Yoichi Ochiai, their laser plasma display is the future of entertainment.

Ochiai has created the first airborne hologram that can be physically felt and manipulated. He’s done so by precisely focusing infrared laser light to selectively ionize, or steal the electrons from, air molecules at the beam’s focal point, generating a flash of bluish-white plasma. Two-hundred-thousand flashes per second are sufficient to generate a three-dimensional moving image.

1. A femtosecond laser system sends out ultrashort bursts of laser light. 2. A spatial light modulator, which adjusts laser intensity using an array of computer-controlled pixels, generates a holographic image. 3. Mirrors focus the beam into position, arranging each individual voxel (the term for 3-D pixels) at specific lateral (X,Y) and axial (Z) points. The focused beam excites the air, ionizing electrons and creating pointsof bluish-white light. 4. A camera captures user interaction. (Credit: Jay Smith after Yoichi Ochiai et al./University of Tsukuba/Utsunomiya University/Nagoya Institute of Technology/The University of Tokyo/Sony CSL)

Ordinarily, plasma is dangerously hot; Ochiai’s tests with nanosecond blasts quickly incinerated bits of leather. But by shortening the bursts from nanoseconds to femtoseconds — quadrillionths of a second — Ochiai’s team can make the plasma safe for fingers. Although the ultrashort bursts do ionize the skin’s surface, turning it into plasma, it’s not long enough to cause damage. Instead, the ionization makes shock waves across the finger’s surface, resulting in a tingling sensation. Ochiai says it feels like touching sandpaper.

Contact with flesh also causes the plasma to brighten, an effect Ochiai plans to exploit for interactive holograms, noting that the brightening can provide a visual cue for video tracking.

Not only can a user touch the hologram, but doing so also can alter the image, allowing for interactive applications in the future. (Credit: Yoichi Ochiai/University of Tsukuba)

And he intends to go big. Ochiai foresees fully immersive holographic experiences in concert halls and stadiums — as well as aerial 3-D markers for roads and runways — all within decades. “I’m a 28-year-old assistant professor,” he remarks. “I think I can make it before my retirement.”
